Components | Specification |
Computer | Industrial Host:
Mother Board : Industrial
CPU : Intel i3/i5/i7 (upgradeable as option)
RAM : 4GB/8GB(upgradeable as option)
HardDisk : 500 G (upgradeable as option)(More sizes and types of PC available upon request) |
Monitor | TFT LCD : 15, 17 or 19 optional
: Brightness 300~1200nits
: Contrast 450:1~1000:1Resolution:15 1024*76817 1280*1024
19 1280*1024More sizes between 20"~46" upon request |
Touchscreen | SAW Touch : 15 17 19"
: Resolution 4096*4096(More types of touchscreen available: capacitive, resistive or IR optional) |
Input Device | 3DES Metal EPP : 16 keys, waterproof, dustproof, vandal proof |
Cash acceptor | optional |
Cash dispenser | optional |
Card Reader | Motorized/Dip :Magcard/IC reader; Shutter(motorized); Confiscate card(motorized) |
Printer | Thermal Printer : Width 80mm~210mm; black mark sensor; full/half cutterDot Matrix : Width 80mm~210mm; black mark sensor; full/half cutterBankbook :24 pin dual direction |
Speaker | Multimedia : Left-right bi-channel amplified output |
Enclosure | ColdRoll Steel : Steel powdercoated front
Powercoated backcover |
OS&Drivers | Windows/Linux/ Unix and all related drivers available |
Packing | Bubble Foam, carton, wooden case |
Other Optionals : UPS, Video Camera, Alarm System, Barcode Scanner, Card Dispenser, Check Acceptor, etc. |
|
